Suzuki VZR1800 / M109R 2006–2009 Service & Owner’s Manual Set (P/N 99500-39293-03E)

736 Pages • ZIP Download: 2 Printable PDFs (English)

4.7starstarstarstarstar_half(3)
$17.80 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Suzuki Models Covered & Key Technical Specifications

Models: VZR1800, Boulevard M109R, Intruder

Sub-models / Variants: VZR1800 (VZR1800K6, VZR1800K7, VZR1800K8, VZR1800ZK8), VZR1800N (VZR1800NK8), VZR1800/N (VZR1800K9, VZR1800NK9), VZR1800UF (identification and label data)

Trade Names: Boulevard M109R, Intruder

Model Years: 2006–2009 (2006, 2007, 2008, 2009)

Serial Numbers: K6 base coverage: JS1CA111200100001– (E-02, U.K.), JS1VY53A 62100001– (E-03/E-28/E-33, U.S.A. except California/Canada/California), JS1CA111100100001– (E-19, E.U.), JS1CA211100100001– (E-19 UF, E.U.), JS1CA121300100001– (E-24, Australia)


  • Engine displacement: 1783 cm³

  • Engine type: 4-stroke, liquid-cooled, DOHC, 54-degree V-twin

  • Number of cylinders: 2

  • Bore: 112.0 mm

  • Transmission type: 5-speed constant mesh

  • Starter system: Electric

  • Coolant capacity: 2.7 L

  • Generator output: Approx. 400 W at 5,000 r/min

Suzuki Manual Features & Selected Content Preview

Publication Pages
Suzuki VZR1800 Service Manual — VZR1800K6 base coverage, with K7, K8/ZK8, NK8 and VZR1800/NK9 differential supplements; Boulevard M109R/Intruder trade names. P/N 99500-39293-03E 609
Suzuki K9 VZR1800/N Owner’s Manual, including the VZR1800N supplementary owner’s section. P/N 99011-48G53-03A 127

The service volume provides workshop inspection and repair procedures; the owner’s volume covers operation and routine care. The service supplements describe model differences and are used with the base information.

VZR1800UF information is limited to market identification and labels. The K9 service supplement provides specification changes and states that its service data is the same as K8.

PDF Search, Bookmarks and Diagram Detail

Search and navigation: Both PDFs contain searchable text. The service manual has embedded bookmarks for its main sections, repair topics and supplements; the owner’s manual has no embedded bookmarks. Small labels in the full wiring diagrams require zooming.

The ZIP download contains two printable English PDFs totaling 736 pages. This total includes the original cover pages, 13 blank or divider pages, the embedded service supplements and the nine-page VZR1800N supplementary owner’s section.


Engine, Shaft-Drive and FI Service Coverage

The following selected topics show the workshop coverage rather than reproduce the complete contents. Additional material includes tire replacement and wheel balancing.

  • Engine repair: Step-by-step removal, teardown and reassembly, including cylinder heads, valves, cam timing, pistons, clutch, transmission, crankcase, balancer, crankshaft, connecting rods and bearing selection.

  • Shaft-drive service: Secondary and final bevel-gear removal, disassembly, inspection, bearing replacement, shim selection, backlash measurement, tooth-contact checks and installation.

  • Fuel injection and emissions: User/dealer modes, Suzuki Diagnosis System checks, DTC resets, ECM terminal tests, TPS/STP adjustment, throttle synchronization, fuel-pressure testing, EXCVA and PAIR diagnosis.

  • Maintenance and cooling: Service schedules, lubrication points, valve-clearance inspection, compression and oil-pressure tests, radiator and thermostat checks, water-pump seal service and cooling-system bleeding.

  • Brakes and chassis: Wheel-bearing replacement, fork seal service, steering adjustment, swingarm and suspension-linkage work, brake-caliper and master-cylinder repair, and brake bleeding.

  • Electrical troubleshooting: Charging-system tests, starter-motor overhaul, starting/interlock diagnosis, ignition checks, instrument and lighting tests, battery service and market-specific wiring diagrams.

  • Owner information: Controls, break-in, pre-ride inspection, loading, routine maintenance, basic fuel/ignition troubleshooting, storage and cleaning.

Suzuki wrote the service manual for people who already have sufficient motorcycle-service knowledge, skills and tools, including special tools; the owner’s manual provides operating and routine-care guidance.

Model Supplements and Regional Differences

The service volume contains 12 core service groups, four differential model supplements and a separate Wiring Diagram section. Regional identification distinguishes U.K., U.S., E.U., Australian, Canadian and California applications.

K7 and K8 changes: K7 adds revised specifications, service data, engine tightening torques and harness routing. K8 adds FI wiring, ECM terminal assignments, fail-safe and malfunction information, O2/PAIR circuit diagnosis and cable routing.

ISC reset and N-model details: The K8/ZK8 section describes the SDS ISC learned-value reset required after throttle-body removal or replacement. The NK8 supplement adds rear-wheel construction, headlight-beam adjustment, wiring, harness layout and front brake-hose routing.

These differences help match the applicable test data and routing information to the model being serviced.

Inspection Data, Diagrams and Workshop Tools

Exploded construction views connect assembly details with tightening torques, lubrication, sealant and replacement notes. References include the FI System Wiring Diagram, Fuel Delivery System diagram, Secondary Bevel Gears and Final Bevel Gears construction views, Engine Lubrication System Chart and market-specific Wiring Diagrams.

DTC charts link detected conditions to circuit checks, sensor tests and ECM terminals. SDS recorded operating data helps relate a fault to the conditions present when it occurred.

Tool references include the SDS set (09904-41010), K8 SDS CD-ROM Ver. 14 (99565-01010-014), mode-select switch (09930-82720), backlash measuring tool (09924-34510) and fuel-pressure gauge adapter (09940-40211). Torque tables, wear limits, fluid capacities, clearances, shim charts and electrical test values support inspection and reassembly planning.

Repair Limits and Component Cautions

Fork and rear-suspension coverage includes seals, bearings and linkage service. The fork cartridge and rear shock absorber unit are not intended for internal disassembly.

Forcing the EXCVA pulley with a wrench can damage the actuator’s internal gear. Final-drive bevel gears are replaced as a matched pair; shim changes affect backlash and tooth contact, so both checks belong together.

Secure the motorcycle with the specified support or engine jack before wheel, suspension or engine work, and follow the manual’s precautions for fuel, hot coolant, brake fluid and electrical isolation.

Preview: Valve Clearances and Bevel-Gear Backlash

For the covered VZR1800 engine, the cold valve-clearance specifications are 0.09–0.16 mm intake and 0.20–0.30 mm exhaust. The inspection section explains the measurement conditions and provides tappet-shim selection tables.

The driveline section specifies secondary bevel-gear backlash of 0.03–0.15 mm and final bevel-gear backlash of 0.08–0.16 mm. Separate shim-adjustment information and tooth-contact illustrations accompany these measurements.
