2005 Polaris Sportsman 700 EFI Owner's Manual (P/N 9919426)

• Official 2005 Polaris Sportsman 700 EFI coverage: 119-page factory Owner’s Manual for Maintenance and Safety, P/N 9919426, Rev 01.
• Explains the Electronic Throttle Control, H/L/N/R/P automatic transmission, On-Demand AWD, hydraulic brake systems, reverse override, and instrument-cluster controls.
• Breaks down all four standard Rider Information Center modes, the separate six-screen gauge diagnostic mode, programmable service reminder, and miles/kilometers selection.
• Contains a single Special EFI Diagnostic Mode blink-code table covering 12 numbered fault-code groups for synchronization, sensors, injectors, ECU memory, warning lamps, and the fuel-pump relay.
• Details owner-level service for the engine oil and filter, transmission, front and rear gearcases, cooling system, brakes, air filter, spark plugs, battery, lighting, wheels, tires, and PVT system.
• Supplies periodic-maintenance and lubrication charts, troubleshooting tables, fluid and load specifications, component torque data, Polaris product part numbers, and an altitude-specific clutching chart.

Coverage and Intended Use

This is the factory owner’s manual for the 2005 Sportsman 700 EFI, identified in the specifications by engine designation EH68ALOE22 and an ECU-controlled electronic fuel-injection system. It is suited to owners who can perform routine inspections, fluid service, and basic ATV maintenance; Polaris directs major repairs to a Factory Certified Master Service Dealer technician and the separate Polaris Service Manual.

Vehicle model, frame VIN, engine serial-number, and key-number locations are illustrated near the front of the manual. The controls section explains the Electronic Throttle Control safety function, combined hydraulic service brakes, auxiliary rear brake, transmission selector, reverse speed limiter, worklight, and automatic front-gearcase engagement through the On-Demand AWD system.

Operating coverage goes well beyond control identification. The manual addresses break-in, the pre-ride checklist, cold-weather operation, cargo distribution and towing, low-range selection, hill climbing and descent, sidehilling, K-turns, water crossings, obstacles, reverse operation, and parking on an incline. Safety sections cover adult-vehicle restrictions, protective equipment, passenger and public-road prohibitions, fuel handling, rollover hazards, and operation on loose, steep, or unfamiliar terrain.

Owner-Level Maintenance and Adjustments

The maintenance section contains scheduled inspection points for steering, suspension, brakes, tires, wheel fasteners, the fuel system, cooling components, wiring, clutches, bearings, and emission-related items. Separate procedures cover engine-oil and filter replacement, transmission oil, both gearcases, radiator and recovery-bottle coolant checks, brake inspection, air-filter service, spark-plug inspection, battery charging, light replacement, vehicle storage, and transport preparation.

Owner-performable adjustments include rear-spring preload, handlebar position, throttle-cable free play, and high- and low-beam aim. Toe alignment can be checked using the illustrated measurement layout, but tie-rod adjustment and front wheel-hub service are assigned to an authorized Polaris dealer.

Water-ingestion coverage is unusually practical for an owner’s publication. It identifies the systems requiring attention after a deep-water crossing, describes the limited emergency response for an immersed ATV, and gives a separate PVT drying procedure. The troubleshooting section then organizes likely causes for drive-belt overheating, failure to crank or start, detonation, backfiring, irregular running, power loss, and engine overheating.

EFI and Instrument Diagnostics

The Rider Information Center has odometer, tripmeter, total-hours, and tachometer modes. Its separate diagnostic mode displays battery voltage, engine speed, AWD-coil status, gear-switch resistance, the programmable service interval, and the distance-unit selection.

The Special EFI Diagnostic Mode reads stored failure codes through the alphanumeric display. Its table distinguishes open-load, short-to-ground, and short-to-battery faults where applicable. Covered circuits include the barometric-pressure and throttle-position sensors, ECU RAM, engine- and intake-air-temperature sensors, both injectors, the temperature and diagnostic lamps, and the pump relay. A no-RPM entry, loss-of-synchronization code, and end-of-transmission indication are also identified.

Specifications, Illustrations, and Repair Scope

Reference tables cover capacities, rack and towing limits, dimensions, engine and ignition data, transmission and final-drive ratios, tires, suspension, brakes, lighting, and wheel-fastener torque. The clutching chart identifies altitude-specific shift weights, drive and driven springs, EBS helix configuration, and the related Polaris part numbers. A separate product table lists the specified engine, transmission, gearcase, coolant, brake-fluid, grease, and storage products by part number.

Useful illustrations include the identification-number locations, instrument-cluster display callouts, toe-alignment setup, transmission and gearcase fill/drain locations, headlamp service and adjustment views, and the clutching chart. This owner’s manual does not contain wiring schematics, connector pinout drawings, full engine or transmission teardown, internal overhaul procedures, or workshop-level repair sequences.

Two maintenance traps are called out clearly. Engaging AWD while the rear wheels are spinning can damage the drive shaft and front gearcase. High-pressure washing can harm wheel bearings, radiator fins, transmission seals, brakes, body panels, and warning labels. Work involving the brake and steering systems, hot coolant, the battery, or the rotating PVT assembly should follow the manual’s safety limits and dealer-service markings.
