2007 Husqvarna TE/TC/SM/SMR Series Workshop Manual
Complete workshop documentation for Husqvarna TE250-TE510, TC250-TC510, SM400-SM510, and SMR450R models. PN 8000 A7735.
Manual Preview
Sample pages from the 2007 Husqvarna TE/TC/SM/SMR Series Workshop Manual manual
Purchase & Download
Models Covered & Key Technical Specifications
Husqvarna 2007 TE/TC/SM/SMR Series Workshop Manual
This manual provides comprehensive documentation for the 2007 Husqvarna TE series, TC series, SM series, and SMR series motorcycles. It details maintenance, troubleshooting, and repair procedures.
- Established Engine Specs: Bore sizes range from 76mm to 97mm depending on the model.
- Operational Timing Specs: Valve angles are set at 12° for intake and 13° for exhaust.
- Essential Fastener Specs: Clutch spring bolts require 8 Nm torque.
- Tolerance Values: Valve clearance for cold engines is 0.10-0.15mm for intake and 0.15-0.20mm for exhaust.
- Amperage Specs: The starter motor is rated at 12V-450W for TE-SMR models.
- Unit Dimensions: Front fork stanchions feature 45mm or 50mm diameters for different models.
Professional Workshop Service Manual & Technical Specifications
Husqvarna 2007 TE/TC/SM/SMR Series Workshop Manual: Technical Documentation
Design-Core: Engine Specifications // Subsystem-Focus: Transmission and Drivetrain Logic // System-Coverage: Chassis, Suspension, Brakes, Electrical System, Fuel System, and Cooling System Details.
Service sections detail the engine, transmission, fuel system, lubrication, cooling, ignition, starting systems, and electrical components. It includes detailed procedures for disassembly, overhauling, and reassembly of the engine, as well as front and rear suspension adjustments.
This manual documents torque specifications for component alignment retention to ensure proper assembly and function.
| Metric | Value | Logic |
|---|---|---|
| Engine Type | 4-stroke, single cylinder | Standard |
| Bore (250) | 76 mm | Engine Specification |
| Bore (400) | 91.5 mm | Engine Specification |
| Bore (450-510) | 97 mm | Engine Specification |
| Stroke (250) | 55 mm | Engine Specification |
| Stroke (400-450) | 60.76 mm | Engine Specification |
| Stroke (510) | 67.8 mm | Engine Specification |
| Displacement (250) | 15.22 cu.in. | Engine Specification |
| Displacement (400) | 24.37 cu.in. | Engine Specification |
| Displacement (450) | 27.39 cu.in. | Engine Specification |
| Displacement (510) | 30.56 cu.in. | Engine Specification |
| Compression Ratio | 12.9:1 | Engine Specification |
This manual serves as a crucial resource for authorized HUSQVARNA service personnel, providing comprehensive guidance for maintenance and repair operations on the listed motorcycle models. Adherence to the technical data presented is essential for the professional development of technicians. The publication includes schematic illustrations to enhance understanding of the topics covered. Methodically demanding procedures are outlined, offering clear diagnostic steps and theoretical foundations that are meant to be supplemented by practical experience and specialized training.
