2007-2009 Suzuki LTZ 90, Z90 ATV repair manual

Price: 18.99 USD
Lifetime Guarantee
File specifications File size: 6.95 MB File ending in: pdf
To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. The following models are encompassed by this manual: LTZ 90, Z90 / Suzuki Motor Corporation 2007 Suzuki LTZ 90 2008 Suzuki LTZ 90 2009 Suzuki LTZ 90 Production year(s): 2007, 2008 Manual Language: English Number of pages: 257 Printable: Yes (with all printers) Instant delivery/download: Your download link will appear on the checkout page after your payment is complete. # ³ "Download the ATV Fix Manual: Explore Engine Specs and More for the 2007-2009 Suzuki LTZ 90, Z90" If you're an owner or enthusiast of the 2007-2009 Suzuki LTZ 90, Z90 ATV, and you're looking for detailed information about its engine specifications, maintenance tips, tuning options, and more, you're in the right place. In this comprehensive guide, we will provide you with a wealth of information about the LTZ 90, Z90 ATV, including engine specs, interesting facts, maintenance intervals, common issues, popular modifications, available accessories, and owner reviews. Whether you're seeking to optimize performance or enhance your overall ATV experience, this guide will equip you with valuable insights. Engine Specs/Technical Specifications: • The 2007-2009 Suzuki LTZ 90, Z90 ATV is powered by a 90cc, air-cooled, four-stroke engine. • It features a single overhead camshaft (SOHC) configuration for efficient power delivery. • The engine incorporates an electric starter system for convenient ignition. • The ATV utilizes a continuously variable transmission (CVT) for smooth acceleration. • It features a forward and reverse gear selection for versatility. • The LTZ 90, Z90 ATV is equipped with a CDI (Capacitor Discharge Ignition) ignition system for reliable performance. • It utilizes a Keihin PTE16 carburetor to ensure optimal fuel delivery. • The ATV features a centrifugal clutch for automatic engagement and disengagement. • It incorporates a chain drive system for efficient power transfer to the wheels. • The LTZ 90, Z90 boasts front independent suspension for improved ride quality. • It features single A-arm front suspension with twin shock absorbers. • The ATV has rear swingarm suspension with a single shock absorber. • It offers a ground clearance of 4.7 inches for tackling various terrains. • The LTZ 90, Z90 ATV has front and rear drum brakes for reliable stopping power. • It features 19-inch front and 18-inch rear tires for optimal traction. • The ATV has a fuel tank capacity of 1.6 gallons for extended riding range. • It offers a seat height of 25.6 inches, suitable for riders of different heights. • The LTZ 90, Z90 has overall dimensions of 57.3 inches in length, 34.1 inches in width, and 36 inches in height. • It has a dry weight of 262 pounds, making it lightweight and maneuverable. • The ATV features front and rear fenders for protection against debris. Facts and Details: - The Suzuki LTZ 90, Z90 ATV is specifically designed for younger riders aged 12 and above. - It offers a user-friendly and approachable riding experience, making it a great entry-level ATV. - The ATV's compact size and lightweight construction allow for easy handling and maneuverability. - The LTZ 90, Z90 features an electric start system, eliminating the hassle of kick-starting. - It is equipped with throttle limiters to adjust the power output according to the rider's skill level. - The ATV incorporates a secure and robust braking system, providing confidence and safety. - It features a comfortable and ergonomically designed seat for extended riding sessions. - The LTZ 90, Z90 ATV's suspension system offers adequate travel for a smooth and controlled ride. - It showcases a sporty and attractive design, reflecting Suzuki's signature aesthetics. - The ATV's engine is known for its reliability and durability, ensuring consistent performance. - It is compliant with safety regulations and features safety features such as a parking brake and safety tether. - The LTZ 90, Z90 ATV has a loyal following among parents and young riders for its performance and dependability. Maintenance Intervals and Tips: To keep your 2007-2009 Suzuki LTZ 90, Z90 ATV in optimal condition, follow these maintenance guidelines: * Oil changes should be performed every 10-15 hours of operation or as recommended in the owner's manual. * Air filters should be inspected and cleaned or replaced every 5-10 hours of operation, depending on conditions. * Regularly check and adjust the chain tension to ensure proper operation. * Maintain proper tire pressure and inspect the tires for wear and damage regularly. * Lubricate all pivot points, control cables, and the throttle assembly as recommended by the manufacturer. * Clean the ATV after each ride to remove dirt, mud, and debris that can cause premature wear. * Check the brakes for proper operation and adjust or replace brake pads as needed. * Regularly inspect the electrical system, including lights and wiring connections, for any signs of damage or corrosion. Common Issues and Solutions: While the LTZ 90, Z90 ATV is reliable, a few common issues may arise. Here are some solutions: + Starting problems: Check the battery for charge and connections, clean the spark plug, and ensure proper fuel flow. + Carburetor issues: Clean or rebuild the carburetor if the ATV experiences fueling or idling problems. + Chain tension problems: Regularly adjust the chain tension and ensure proper lubrication to prevent excessive wear. + Electrical issues: Inspect the wiring harness for loose connections or damaged wires. Replace any faulty components. Popular Tuning Tips or Modifications: ■ Install an aftermarket exhaust system for improved power and a more aggressive sound. ■ Upgrade the air filter to a high-flow performance filter for increased airflow and enhanced engine performance. ■ Consider installing a jet kit to optimize fuel delivery for better throttle response. ■ Replace the stock tires with more aggressive off-road tires for improved traction on various terrains. ■ Install a nerf bar or skid plate for added protection against trail obstacles. ■ Upgrade the suspension components, such as shocks and springs, for a smoother and more controlled ride. Accessories and Aftermarket Options: Nerf bars and footpegs for improved rider comfort and protection. Skid plates and A-arm guards for enhanced undercarriage protection. Handguards and brush deflectors for shielding hands from branches and debris. Storage racks and cargo bags for additional carrying capacity. LED light kits for improved visibility during nighttime riding. Performance air filters and intake systems for increased airflow and power. Owner Reviews and Opinions: Strengths: Suitable for young riders, offering a safe and fun ATV experience. Reliable engine performance and ease of maintenance. Comfortable seating and ergonomic design for long rides. User-friendly controls and throttle limiters for customizable power output. Good value for the price. Weaknesses: Limited top speed compared to larger ATVs. Lower ground clearance may limit off-road capabilities. Limited storage options for carrying gear. Begin your troubleshooting journey with the Suzuki LTZ 90, Z90 ATV by purchasing and downloading the detailed shop manual in PDF format. Simply click the green button and securely buy it from the RepairLoader marketplace using PayPal. After completing your PayPal payment, you will receive an email with the payment and download information. On the checkout page, the official Suzuki OEM shop manual/parts list download link will appear, and it will be emailed to you immediately. §
