Xerox Models Covered & Key Technical Specifications

Models & Model Codes: Phaser 8510MFP, Phaser 8560MFP (CXF)

Sub-models / Variants: 8510MFP/N, 8510MFP/D, 8560MFP/D, 8560MFP/T, 8560MFP/X

Model Year: 2006


  • Printing process: Solid-ink

  • Warm-up time: 12 minutes from cold start

  • Maximum RAM: 1 GB

  • Input tray capacity: Tray 1: 100 sheets, Trays 2-4: 525 sheets each

  • Output tray capacity: 250 sheets facedown

  • Print speed: Up to 30 ppm (8560MFP), 24 ppm (8510MFP)

  • Power consumption: 1500 W peak

Xerox Manual Features & Selected Content Preview

This Xerox service manual (P/N 705P01133) covers the Phaser 8510MFP/N, 8510MFP/D, 8560MFP/D, 8560MFP/T, and 8560MFP/X. It is the October 2006 edition with the November 1, 2006 reissue update.

Finding Service Procedures and Wiring Details

Search and diagram detail. The text and diagram captions are searchable, and embedded bookmarks cover the introduction and all eight service chapters. Small pin numbers, connector IDs, and signal labels inside the wiring images are easier to read when zoomed in.

The download is one printable PDF with 296 pages, including the original Xerox cover and 11 pages that contain only running footers.


Print Engine, Paper Path, and Scanner Service

These are selected procedures and diagnostic topics. The manual also covers routine feed-roller cleaning and maintenance-counter checks.

  • Print engine. Step-by-step removal and replacement procedures cover the Printhead, Ink Loader, Drum Assembly, and Purge Pressure Pump, with component-specific installation checks.

  • Drum and transfix service. Replacement procedures cover the Transfix Roller, Transfix Camshaft, Drum Maintenance Camshaft, and Drum Maintenance Pivot Plate.

  • Drive alignment and homing. Dedicated adjustments cover Process Drive alignment, Wiper Blade alignment, and homing the Head Tilt Gear and Printhead.

  • Scanner and document feeder. Scanner Assembly and Duplex Automatic Document Feeder (DADF) replacement procedures include DADF-to-scanner calibration for grayscale, margins, and front-to-back alignment.

  • Paper path. Repair procedures cover pick and retard rollers, the Preheater and Deskew Assembly, duplex transport components, and the Exit Module’s roller and elevator motors.

  • Control Panel diagnostics. Tests cover motors, clutches, solenoids, sensors, and heaters. Startup troubleshooting explains built-in self-tests (BIST), power-on self-tests (POST), print engine self-tests (PEST), and LED blink codes.

Xerox wrote this manual for certified service technicians trained on these models.

Model and Option Coverage

The configuration tables distinguish the 8510MFP’s Flash Disk from the 8560MFP’s Hard Drive and identify differences in automatic duplexing, feeder options, and advanced copy and fax features. Both models support memory expansion.

The manual explains PagePack metered operation, lists separate metered and non-metered Ink Loaders, and gives a replacement procedure for the optional Foreign Device Interface board.

Image Quality and Fault Isolation

Image-quality procedures help distinguish print-engine defects from Scanner and DADF problems. They cover streaks, voids, misaligned output, ghosting, oil streaks, incomplete image transfer, and first-side duplex smears. Service test prints help identify weak or missing jets, and the Jet Substitution Mode section explains the limits of compensating with adjacent jets.

Fault-code procedures link symptoms to applicable parts, wiring references, and tests for the printhead jetstack and reservoir thermal sensors, ink-melt heaters, and drive assemblies. The Engine Error History, Jam History, Service Usage Profile, and power-on timing chart help narrow down faults. Code coverage focuses on common hardware faults and jam combinations and includes selected program faults.

The Check Menu covers Y-axis encoder, belt-slip, belt-tension, paper-edge timing, and transfix-gap tests. Many tables show N/A for typical values. The descriptions explain what each test does and what it reports.

The manual covers Ethernet and USB port verification, fax modem tests, and interpretation of Fax Transmission and Protocol Reports. Serial Back Channel Trace capture uses a null-modem cable (P/N 012153500) and diagnostic serial adapter (P/N 012154300). The computer-side checks reflect the Windows XP and Mac OS X environments of this edition.

Electronics Replacement and Reassembly

Separate procedures cover the Wave Amplifier, I/O Board, Scanner Power Supply, and Drum Heater Relay Board. The Electronics Module is serviced as an assembly. Its replacement procedure covers transferring the RAM, NVRAM, Configuration Card, and Hard Drive or Flash Disk.

Incorrect homing can damage the Process Drive during initialization. Improperly seated ribbon cables can damage the Wave Amplifier. DADF-to-scanner calibration calls for the Scanner Calibration Page (P/N 109K02110) supplied with the replacement part.

Theory of Operation connects drum oiling, printhead movement, pressure purging, and transfix loading. These relationships help narrow down defects that can involve more than one drive or maintenance assembly. Follow Xerox’s power-isolation and printhead cooling precautions when servicing internal components.

Wiring, Parts, and Service Tools

Wiring diagrams are paired with plug/jack location maps and harness-routing views. The Scanner/DADF Block Diagram follows the image-input electronics, and Electronics Module Power shows power connections. Right Side Harness / I/O Control covers engine-drive connections, while Exit Module Control Board shows output-transport connections. Process Drive Gear Alignment shows the gear-position references for reassembly.

Illustrated parts lists link assembly callouts to part numbers and service kits. Specifications cover print-engine and scanner performance, media limits, image skew, and margins. The service-tool list identifies torque screwdriver P/N 003082700.

Sample Drum Fastener and DC Test Specifications

The Drum Assembly replacement procedure specifies 25 in-lb for the screws that secure the assembly to the chassis.

The electrical reference table gives a range of +4.75 to +5.25 VDC for the nominal +5 VDC supply, measured relative to the specified DC common unless the diagnostic procedure names another reference point.
