Honda Rancher 420 (TRX420) ATV Service Manual, 2007–2011
589 Pages • Printable PDF • 75.58 MB • Download
Honda Models Covered & Key Technical Specifications
Model: Rancher 420 (TRX420)
Sub-models / Variants: TRX420FE (ESP), TRX420FM (left-foot gearshift), TRX420TE (ESP), TRX420TM (left-foot gearshift), TRX420FPE (ESP, EPS), TRX420FPM (left-foot gearshift, EPS)
Model Years: 2007–2011 (2007, 2008, 2009, 2010, 2011)
-
Engine: Single cylinder, longitudinally installed, 420 cc displacement
-
Cooling System: Liquid cooled
-
Fuel System: PGM-FI (Programmed Fuel Injection)
-
Transmission: 5-speed constant mesh with reverse
-
Drive System: 2WD (TM/TE models), 4WD with selectable front final clutch (FM/FE/FPM/FPE models)
-
Curb Weight: 248 kg – 275 kg (varies by model)
-
Suspension: Double wishbone front, swingarm rear
Honda Manual Features & Selected Content Preview
Honda service manual for the 2007–2011 Rancher 420, covering TRX420FE, TRX420FM, TRX420TE, TRX420TM, TRX420FPE, and TRX420FPM variants. Procedures distinguish foot-operated shifting, Electric Shift Program (ESP), and Electric Power Steering (EPS) configurations.
PDF Bookmarks and Wiring Detail
Search and navigation: Embedded bookmarks provide access to the chapters and individual wiring diagrams. PDF text search does not cover the service pages. Small wire-color codes and connector labels on the checked wiring diagrams require zooming.
Supplied as one printable, English-language PDF with 589 pages, including one added cover page.
Engine, Driveline, and Electronic System Service
The following selected coverage highlights outline the main repair areas. Additional topics include body-panel removal and exhaust-system service.
-
Engine repair: Step-by-step procedures for engine removal, cylinder-head disassembly, valve-guide replacement, valve-seat refacing, piston installation, and camshaft timing.
-
Clutch and transmission: Centrifugal and change-clutch disassembly, gearshift-linkage inspection, crankcase separation, transmission service, and crankshaft/balancer work.
-
PGM-FI diagnosis: DTC charts, fuel-pressure and delivery tests, injector inspection, sensor-circuit troubleshooting, and throttle-position sensor reset procedures.
-
Cooling and lubrication: Cooling-system pressure testing, thermostat inspection, water-pump seal replacement, oil-pump inspection, and relief-valve service.
-
Chassis and brakes: Wheel-bearing replacement, suspension-arm and swingarm service, steering-shaft inspection, front hydraulic brake bleeding, and rear drum-brake repair.
-
Final drives: Front differential and final-clutch service on applicable models, rear final-drive overhaul, propeller-shaft inspection, and gear-case bearing replacement.
-
Electrical controls: Charging, ignition, and starter tests; ESP fault tracing; EPS DTC diagnosis and torque-sensor initialization on applicable variants.
Honda intended this manual for qualified professional technicians; some procedures require dedicated equipment and model-specific service tools.
Internal Engine and Transmission Work
Cylinder-head and piston service can be performed with the engine installed. Internal transmission, crankshaft/balancer, and alternator/starter-clutch work require engine removal, helping technicians plan the extent of disassembly before a larger repair.
Inspection sections provide component wear limits alongside engine, frame, and suspension torque tables. The clutch procedures distinguish the different clutch-disc arrangements used with foot-operated and electric shifting.
The oil-filter instructions identify a specific assembly hazard: installing the filter backward can cause severe engine damage.
Fuel Injection, Cooling, and Lubrication
The PGM-FI System Diagram and connector terminal views support circuit testing at the sensors and PCM/ECM. Diagnostic information covers HDS Pocket Tester use and MIL blink-code retrieval, with separate troubleshooting for starting, idle, and fuel-delivery complaints.
Throttle-body work includes the required TP sensor reset after sensor removal or replacement. The sub-fuel-tank/fuel-pump assembly is replaced as a unit rather than internally disassembled.
The Cooling System Flow Pattern and Lubrication System Diagram show the coolant and oil paths alongside the related component procedures. Water-pump repair includes mechanical-seal inspection and the associated impeller and shaft replacement requirements.
ESP and EPS Diagnostics
The PCM combines engine management and ESP control. The diagnostic notes explain how shared sensor faults can affect both systems, while ESP troubleshooting distinguishes electrical shift failures from mechanical gearbox or linkage faults.
EPS coverage includes connector locations, torque-sensor circuit tests, ECU replacement, and torque-sensor initialization after specified steering work. The electrical service notes warn that disconnecting EPS ECU connectors while current is flowing can damage the ECU.
Final Drives, Brakes, and Harness Routing
Final-drive overhaul extends to tooth-contact pattern checks, backlash measurement, and shim selection. Front final-clutch assembly views identify the lock spring, collar, shift fork, and pinion joint.
Factory cable and harness routing maps show where the main harness, EPS wires, and brake lines must be secured during frame-up reassembly. Model-specific wiring diagrams distinguish the relevant shifting, steering, and market configurations.
Heavy ATV maintenance requires strict adherence to shop safety protocols, including the use of secure jack stands and proper protective gear. Follow the manual’s precautions for fuel-system pressure, hot coolant, and brake service.
Preview of Maintenance Capacities and Clearances
Engine oil capacity is specified as 2.7 liters after draining. On FM/FE/FPM/FPE models, front final-drive oil capacity is 230 cm³ after draining; the manual lists separate capacities after disassembly.
Spark plug gap is 1.0–1.1 mm. Intake valve clearance is 0.15 ± 0.02 mm with the engine cold, below 35°C/95°F. These values accompany the maintenance inspection and adjustment procedures.
