2012 Hyundai Accent 1.6L GDI Service Manual

Technical Documentation for the 2012 Hyundai Accent 1.6L GDI

• Covers the 2012 Hyundai Accent 1.6L GDI equipped with the A6GF1 automatic transaxle system
• Original OEM publication, Form No. not specified, dated 2012
• Contains 56 exploded-view components diagrams and 3 electrical schematic diagrams
• Includes a complete solenoid valve operation table and TCM terminal input/output signal pinout reference
• Downloads to your account within seconds of checkout
• Re-download the file any time, no expiration
• OCR text layer lets you jump to a torque spec by keyword
• Indexed PDF search covers every chapter and appendix
• This 2012 edition documents the specific A6GF1 transaxle control architecture exclusive to the Gamma 1.6L GDI powertrain

Automatic Transaxle System Breakdown

This manual documents the 2012 Hyundai Accent 1.6L GDI automatic transmission assembly. The documentation details the hydraulic system, describing the roles of the oil pump, filter, and valve body in managing clutch and brake engagement. It outlines the specific power flow routes for each gear setting, including the function of the overdrive clutch, one-way clutch, and various brake chambers. Furthermore, the sections detail the removal and installation of the transaxle, including lifting requirements and safety precautions.

Specification and Electronic Control Reference

The technical data preview includes tightening torque tables for standard bolts and transaxle-specific fasteners, such as the 45.1–52.0 Nm torque converter mounting bolt specification. Electrical system data covers the Transaxle Control Module (TCM), providing terminal function tables and signal values for sensors and solenoids. Sensor reference values are provided, such as the NTC oil temperature sensor resistance, which is 5.88 kΩ at 0°C (32°F). Solenoid operation is documented for all VFS and ON/OFF valves, including internal resistance and control pressure ranges. This factory workshop documentation provides the required diagnostic thresholds for input and output speed sensors to assist with complex drivetrain analysis. Reference only — always consult a certified technician before performing service on this equipment. An official 91-page Hyundai OEM workshop manual covering the 2012 Hyundai Accent 1.6L GDI, documenting transaxle, hydraulic, and electrical control system specifications for the A6GF1 assembly.
