Suzuki King Quad 500AXi 2009 ATV Service Manual (P/N 99500-44080-03E)

624 Pages • Printable PDF • 35.01 MB • Download

5.0starstarstarstarstar(1)
$17.99 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Suzuki Models Covered & Key Technical Specifications

Models: King Quad 500AXi

Sub-models / Variants: LT-A500XP (LT-A500XPK9: P-17 Sweden, P-24 Australia, P-28 Canada, P-33 U.S.A.); LT-A500XPZ (LT-A500XPZK9: P-17 Sweden, P-24 Australia, P-28 Canada, P-33 U.S.A.)

Model Year: 2009

Serial Numbers: 5SAAM45P97100001–


  • Engine displacement: 493 cm3

  • Engine type: 4-stroke, liquid-cooled, OHC

  • Number of cylinders: 1

  • Compression ratio: 10.0:1

  • Transmission type: CVT (V-belt) with 2-speed transfer

  • Fuel type: Unleaded gasoline (USA/Canada: at least 87 pump octane or 91 RON; other markets: at least 91 RON)

  • Brake system (front): Dual disc brakes

  • Brake system (rear): Sealed oil-bathed multi-disc

  • Idle speed: 1,500 ± 100 r/min

  • Drive system: Shaft drive

Suzuki Manual Features & Selected Content Preview

This Suzuki Motor Corporation factory service manual covers the 2009 King Quad 500AXi LT-A500XP/Z models. The December 2008 edition carries P/N 99500-44080-03E and contains inspection, service and overhaul procedures.

PDF Search, Navigation and Page Count

Finding procedures and wiring details: Searchable PDF text and embedded bookmarks provide access to the technical sections. Dense wiring diagrams require zooming to read the smallest wire-color codes and connector labels.

One printable, English-language 624-page PDF, including the foreword, contents pages, two blank pages and final publication page.


Engine Overhaul, CVT Service and EPS Diagnosis

The following highlights are a selection of the covered work. Other included topics range from spark-arrester inspection to headlight-beam adjustment.

  • Engine repair: Valve-clearance adjustment, engine removal, and top-end and crankcase overhaul procedures, with component inspection limits and tightening specifications.

  • Fuel injection: Suzuki Diagnosis System (SDS) checks, diagnostic trouble codes, sensor-circuit troubleshooting, fuel-pressure testing and fuel-pump delivery inspection.

  • CVT and clutch: Step-by-step drive V-belt replacement, drive-face disassembly, driven-face service, centrifugal-clutch inspection and shift-rod adjustment.

  • Driveline: Front differential, final gear, transfer and propeller-shaft service, including backlash measurement, tooth-contact checks and shim selection.

  • Power steering: EPS fault diagnosis, SDS checks, motor-circuit testing, and removal and installation of the control unit and EPS body assembly.

  • Brake service: Front caliper and master-cylinder overhaul, hydraulic bleeding, rear friction-plate replacement, and parking-brake cable inspection and adjustment.

  • Suspension and steering: Shock-absorber replacement, spring-preload adjustment, hub-bearing replacement, suspension-arm service, and steering-shaft and tie-rod inspection.

Written for people with the knowledge, skills and tools needed to service Suzuki vehicles, this manual assumes mechanical experience and access to the specified special tools.

Engine Internals, Lubrication and Cooling

Cylinder-head work extends to valve-guide replacement and valve-seat repair. Piston, ring, camshaft and crankshaft inspection tables distinguish standard dimensions from service limits.

The Periodic Maintenance Schedule Chart organizes routine inspections and replacements. The manual also identifies components that can be serviced with the engine still installed, helping technicians assess the extent of a job before removal.

Lubrication and cooling coverage includes oil-pressure checks, oil-pump inspection, radiator-cap testing, thermostat checks and water-pump disassembly. The Engine Lubrication Circuit Diagram and Water Hose Routing Diagram support these procedures.

EFI Testing and Electrical Fault Isolation

Electrical pinouts and resistance specifications support component testing before replacement decisions. The FI diagnostic charts distinguish sensor and actuator faults from connector, power-supply and wiring problems.

The injection-timing explanation is accompanied by SDS data checks, stored fault information and ISC RPM active-control testing. Fuel-system procedures cover pump removal, mesh-filter cleaning, injector inspection and delivery-pipe service.

An ISC-valve caution explains how premature ECM or ISC-coupler disconnection after shutdown can store an incorrect valve position and cause idle-control errors.

CVT Wear Checks and Driveline Setup

The transmission section separates drive-belt wear, pulley-face condition, roller wear and clutch engagement checks. Clutch-housing and driven-spring inspection data provide criteria for assessing removed components.

Front differential and final-gear procedures include separate shim tables and tooth-contact examples. Rear output-shaft bevel-gear setup is also covered, with backlash and contact-pattern checks tied to the relevant assembly.

EPS Service Boundaries

Dedicated troubleshooting charts address torque-sensor signals, motor circuits, supply voltage and vehicle-speed inputs.

Assembly-level service: EPS body removal and replacement are covered, but internal disassembly is prohibited. The manual warns that removing the torque sensor can cause damage.

Brake and steering work affects vehicle control; the manual includes system-specific precautions for these repairs.

Wiring and Circuit References

Regional wiring diagrams distinguish P-17 equipment from P-24, P-28 and P-33 configurations. The FI System Wiring Diagram, Fuel Hose Routing Diagram and EPS System Wiring Harness Routing Diagram provide references for tracing circuits and checking component routing.

Separate electrical sections cover no-spark diagnosis, starter-motor overhaul, starting interlocks, generator tests, regulated-voltage checks and regulator/rectifier inspection.

Selected Valve, Ignition and Fuel-Test Specifications

Cold valve-clearance specifications are 0.05–0.10 mm for the intake valves and 0.17–0.22 mm for the exhaust valves. Spark-plug service data lists a gap of 0.7–0.8 mm.

The CKP sensor inspection specifies 170–250 ohms between the blue and white leads, alongside separate peak-voltage and wiring checks.

Fuel-pump delivery is specified as at least 55.5 ml in 10 seconds during the manual’s 12 V test, with the battery fully charged.
