Massey Ferguson 340/350/355/360/399 Tractor Shop Manual – 1986–1993

221 Pages • 1 Printable PDF (English) • Download

4.6starstarstarstarstar_half(5)
$24.39 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Massey-Ferguson Models Covered & Key Technical Specifications

Models: 340, 350, 355, 360, 399

Models & Model Codes:

340 — 4WD: 5747, 5812

350 — 2WD: 5000; 4WD: 5001

355 — 2WD: 5309; 4WD: 5310

360 — 2WD: 5221; 4WD: 5222

399 — 2WD: 5012; 4WD: 5013

Sub-models / Variants: 2WD, 4WD, Early 399, Late 399

Model Years: 1986–1993 (1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993)

Serial Numbers: Late 399 with 1006.6 engine: beginning with S01001; disc-brake configurations: before V39466 / after V39465; non-adjustable hydraulic relief cartridge: some tractors from N42314.

Engine Serial Breaks: 355: before U796442P / after U796441P; early 399: before U793031P / after U793030P.

Wiring Diagram Serial Ranges: Up to V52267 (all models); V52268–P22199 (cab); V52268–R15000 (three-cylinder, non-cab) or V52268–R14231 (six-cylinder, non-cab); R15001–S00000 (three-cylinder, non-cab) or R14232–S00000 (six-cylinder, non-cab); R15196–S00000 (three-cylinder, cab) or R15159–S00000 (six-cylinder, cab); after S01000 (cab and non-cab).


  • Engine Makes: Perkins

  • Engine Models: AD3.152S (340, 350; CE31160), AT3.1524 (355: CN31187; 360: CN31185), A6.3544 (Early 399; TW31159), 1006.6 (Late 399; YA31240)

  • Transmission Variants: Eight-speed standard (350, 355, 360); eight-speed synchromesh (340, 350, 355, 360); six-speed shuttle (360); eight-speed shuttle (340, 350, 355, 360); twelve-speed synchromesh (350, 355, 360, 399); twelve-speed shuttle (399)

  • Cylinder Count: 3 (340–360), 6 (399)

  • Compression Ratio: 16:1, 15.5:1, 16.5:1

  • Bore Range: 91.4 mm to 100 mm

  • Displacement Range: 2.5 L to 6.0 L

  • Battery Ground: Negative

Massey-Ferguson Manual Features & Selected Content Preview

This shop manual covers Massey Ferguson 340, 350, 355, 360, and 399 tractors, 1986–1993, in applicable 2WD and 4WD configurations.

PDF Search, Bookmarks and Page Count

Finding text and diagram details: OCR text search is available in the index and repair chapters, but small wiring-diagram labels are not consistently searchable. The embedded bookmarks have numeric labels rather than chapter names. Small component numbers, connector pin numbers, and wire-color codes require zooming.

One printable English PDF contains 221 pages, spanning printed pages 5–212. Thirteen pages repeat earlier content and are already included in that total.


Engine, Drivetrain and Hydraulic Repair Coverage

These selected repair topics outline the scope rather than reproduce the full index. Other subjects include fuel-filter maintenance and brake master-cylinder service.

  • Perkins engine repair: Engine removal, cylinder-head and valve work, timing gears, pistons and sleeves, crankshaft bearings, lubrication, cooling, and Holset turbocharger service.

  • Transmission overhaul: Standard, synchromesh, and shuttle gearboxes, with step-by-step transmission removal, shaft and gear service, synchronizer setup, and bearing-preload procedures.

  • Axles, steering, and brakes: 2WD and mechanical front-wheel-drive axles, differential service, hydrostatic steering pressure checks and bleeding, plus drum- and disc-brake repair.

  • Hydraulics and PTO: Troubleshooting, pressure and flow testing, lift-pump and lift-cover repair, draft and position-control adjustment, auxiliary valves, and live and independent PTO service.

  • Diesel fuel system: Bleeding, injector fault isolation and bench testing, nozzle service, and injection-pump removal and timing.

  • Electrical diagnosis: Lucas and Motorola alternator testing, Lucas and Perkins starter illustrations, and eleven serial-specific wiring diagrams for cab and non-cab tractors.

This shop manual is suited to experienced mechanics and repair shops equipped for tractor splitting, hydraulic pressure testing, injector testing, and press work. Several jobs call for dedicated Massey Ferguson service tools or suitable equivalents.

Engine Builds, Injection Pumps and Turbochargers

The engine chapters distinguish AD3.152S, turbocharged AT3.1524, early-399 A6.3544, and late-399 1006.6 installations. The late-399 branch begins with serial S01001 for 1991 and later.

Engine build codes and injection-pump tables help match pump and timing data to the installed engine, including the 355 and early-399 engine-serial changes.

Injection-pump limits: Internal CAV injection-pump overhaul is outside this manual's repair coverage. The publication reserves sealed-pump service for trained personnel with the proper testing and adjustment equipment.

The Holset turbocharger exploded view supports the inspection and overhaul material. Its handling caution explains that resting the assembly on the compressor impeller or turbine wheel can damage the blades under the unit's own weight.

Clutches, Transmission Setup and PTO

Cab and non-cab tractor-splitting procedures accompany the configuration-specific transmission chapters. Dual and split-torque clutch assemblies are treated separately; independent PTO material covers its hydraulic clutch, brake, control valve, and pressure tests.

The twelve-speed shuttle section adds range-change gearbox service, shift-fork centering, upper-shaft bearing preload, and an exploded assembly and cross-section. Its bearing-handling warning links hammer-and-punch work to concealed damage, seizure, and failure of other transmission components.

4WD, Rear Axles and Brake Variants

The front-drive chapters distinguish conventional, Autolock, and Hydralock differentials, including a Hydralock exploded view and section. Transfer-gearbox coverage separates units before and from July 1991, plus the unit used with the twelve-speed shuttle.

Rear-axle material separates the 340's direct-drive axle from planetary final drives on the other models. Early 340 drum brakes, later 340 disc brakes, and the disc-brake control changes at the listed serial breaks have their own service instructions.

Lift Hydraulics and Draft-Control Adjustment

The main four-piston lift pump and two-section auxiliary system have separate testing and repair material. The steering chapters distinguish separate and tandem pumps, with the corresponding pressure-test arrangements and component overhaul instructions.

Lift-linkage setup: Intermix and non-intermix draft-control adjustment views distinguish the arrangements used on 399 tractors. The instructions identify MF273, MF356C, MF445, and MF272 setup tools; the auxiliary spool-valve exploded section distinguishes detent, spring-return, and float arrangements.

Electrical References and Service Specifications

A wire-color legend and numbered component and connector references accompany the three- and six-cylinder circuit drawings. These are typical diagrams; wiring on individual tractors may differ.

Component-specific torque specifications, pressure-test data, capacities, clearances, wear limits, and adjustment information are given in U.S. customary and metric units.

Tractor splitting, axle and flywheel handling, injector testing, and hydraulic pressure checks require secure support, suitable lifting equipment, and the pressure-safety practices stated in the manual.

Examples of Alternator and Water-Pump Inspection Data

For the Motorola alternator, the rotor test specifies 4.0–5.2 ohms between the slip rings. The brush inspection permits reuse with at least 5 mm protruding from the holder, provided the brushes are neither oil-soaked nor cracked.

The three-cylinder water-pump assembly instructions specify 0.25–0.51 mm clearance between the front of the impeller and the inside of the pump body.

Customer Reviews

Read what our customers say about this Massey-Ferguson Tractor manual and share your own experience.

Checkout
Massey Ferguson 340/350/355/360/399 Tractor Shop Manual – 1986–1993 $24.39
