Arctic Cat 450 ATV Service Manual – 2013 (P/N 2259-526)
128 Pages • Printable PDF • 19.51 MB • Download
Arctic Cat Models Covered & Key Technical Specifications
Model: 450
Model Year: 2013
-
Engine coolant capacity: 2.9 L
-
Front tire size: 25 x 8-12
-
Rear tire size: 25 x 10-12
-
Ignition timing: 10° BTDC @ 1500 RPM
-
AC generator output: 60 AC volts @ 5000 RPM
-
Front differential lubricant capacity: 275 ml
-
Rear drive lubricant capacity: 250 ml
-
Engine oil capacity (change): 2.8 L
Arctic Cat Manual Features & Selected Content Preview
This Arctic Cat factory service manual covers the 2013 Arctic Cat 450 ATV. P/N 2259-526, dated September 2012, contains maintenance, repair, and troubleshooting information for the engine/transmission, EFI, electrical system, drivetrain, and chassis.
Searchable Text and Wiring Diagram Limits
Search, bookmarks, and diagram detail: The service text is searchable, with embedded bookmarks for chapters and many individual procedures. The cover and back cover lack searchable text, and most labels within the appended wiring diagram are not searchable. Small wiring labels require zooming; some remain blurred at higher magnification.
One printable, English-language 128-page PDF includes 124 numbered manual pages, the front cover, foreword, back cover, and one appended wiring-diagram page.
Engine, EFI, Drivetrain and Chassis Service
The following highlights are a selection of the manual’s contents. Other topics include storage preparation and headlight aiming.
-
Engine/transmission: Step-by-step removal, crankcase separation, cylinder-head and camshaft work, piston/cylinder inspection, CVT and centrifugal-clutch service, and internal transmission assembly.
-
Fuel, lubrication, and cooling: Throttle-body removal, fuel-pump and oil-pressure tests, fuel-level sender checks, radiator service, thermostat testing, and water-pump replacement.
-
EFI and electrical diagnosis: LCD-gauge diagnostic modes, sensor and circuit tests, DTC interpretation, charging-system diagnosis, starter checks, and TPS adjustment.
-
Drive system: Front differential and rear gear case service, bevel-gear shimming, backlash and end-play adjustment, drive-axle removal, hub service, and actuator replacement.
-
Brakes, suspension, and steering: Hydraulic brake bleeding, caliper rebuilding, pad replacement, A-arm and shock service, steering-knuckle bearings, steering post/tie rods, and toe-out adjustment.
-
Maintenance and references: Periodic Maintenance Chart, lubrication points, valve-clearance inspection, compression testing, fluid specifications, wear limits, and component-specific Torque Specifications.
The manual is written for service personnel and assumes access to workshop measuring equipment and the specified special tools.
Engine Access and Internal Repair
Top-side, left-side, and right-side components can be serviced with the powertrain in the frame; center-crankcase work requires engine/transmission removal. This distinction helps you plan access and disassembly before starting a repair.
The internal procedures extend to the crankshaft, countershaft, shift forks, reverse idler, secondary gears, and balancer shaft. Illustrated cam-chain timing and magneto/starter-clutch procedures accompany piston, cylinder, valve, and camshaft inspections.
The cam-sprocket illustrations identify alignment-pin/tab-washer errors that can cause severe engine damage; the countershaft instructions warn that reversed dogs or gears can damage the transmission.
Service limits: The oil pump, water pump, and driven pulley are replaced as complete assemblies. The crankshaft/connecting-rod assembly is also non-serviceable internally; specialist valve, valve-guide, and valve-seat work is referred to a qualified machine shop.
EFI Tests and Electrical Fault Tracing
The gauge supports static and dynamic checks through COOL, FUEL, tACH, SPd, tPS, bArO, AIr, and bAtt modes. These connect sensor readings with operating conditions; for example, COOL mode supports checking coolant-temperature signals and fan operation.
The EFI Diagnostic Trouble Codes table links faults to ECM pins and distinguishes low, high, open, and intermittent circuit conditions. Coverage includes TPS, MAP/IAT, ECT, fuel-pump relay, injector, crankshaft sensor, fan relay, starter circuit, ignition coil, system voltage, and gauge communication.
Charging tests address the stator and regulator/rectifier, alongside front drive selector, tilt-sensor, and lighting-circuit checks. The TPS installation procedure specifies 0.68 DC volts with the TPS Analyzer Tool and Multi-Analyzer Harness connector #8; this is an analyzer-setting value, not a general harness-voltage specification. Defective starter motors and ECMs are replaced as assemblies.
Appended schematic: The full-page Main Harness diagram is labeled 400 CR, with harness p/n 0486-469. Its labeling differs from the 450 EFI model covered by the service text; check its applicability before relying on it for wiring work.
Gear Setup, Brakes and Chassis
Drive-system instructions cover input-shaft and pinion service, axle seals and bearings, and gear-set setup. Secondary-gear Tooth Contact/Shim Correction illustrations and Backlash Measurement/Shim Correction data explain how gear contact relates to shim selection.
Ring-gear specifications include 0.28–0.38 mm backlash and 0.1–0.2 mm end play. The front differential and rear gear case use opposite lock-collar thread directions, and the manual warns that remaining staked material can destroy the housing threads during removal.
Repair boundaries: The front drive actuator and shock absorbers are replacement assemblies. Internal axle disassembly is referred to the applicable boot-kit instructions.
Caliper coverage includes piston/seal inspection and reassembly; the hand-brake master cylinder is replaced as an assembly. The hydraulic system specifies DOT 4 fluid.
Chassis procedures also address the LCD gauge, throttle control, frame, racks, and body panels. Toe-out is specified at 1/8–1/4 in., with correctly inflated tires and normal operating load without an operator.
Because ATV service involves heavy components, pressurized gasoline, hydraulic brake fluid, and supported suspension/drivetrain assemblies, use a stable work area and follow the manual’s warnings, support requirements, fluid-handling precautions, and specified torque values. Arctic Cat recommends authorized dealers for hydraulic brake service.
Specified Workshop Tools
Tool references include Crankcase Separator/Crankshaft Remover 0444-152 and Magneto Rotor Remover Set 0444-254 for engine work.
Diagnostic equipment includes Oil Pressure Test Kit 0644-495 and Peak Voltage Reading Adapter 0644-307. Gear-case procedures identify Backlash Measuring Tool 0544-010 and Pinion Gear/Shaft Removal Tool 0444-127.
A Sample of Valve, Pressure and Maintenance Specifications
Valve/tappet inspection uses 0.076–0.127 mm intake and 0.152–0.203 mm exhaust clearances. The compression test specifies 95–115 psi with a warm engine, fully charged battery, and fully open throttle.
Oil-pressure testing specifies 0.6–0.7 kg/cm² (8.5–10 psi) at 3000 RPM with the engine at normal operating temperature and the cooling fan cycling. The electric fuel-pump test specifies 43 psi as pressure builds with the ignition on until the pump shuts off.
Maintenance data specifies a 3.3 L (3.5 U.S. qt) engine-oil fill after overhaul and lists 28.5 mm (1.12 in.) as the minimum drive-belt width.
