2006 Arctic Cat 400, 500, 650, TBX, TRV, H1, V-Twin 4x4 manual Preview image 1

2006 Arctic Cat 400, 500, 650, TBX, TRV, H1, V-Twin 4x4 manual Preview image 2

2006 Arctic Cat 400, 500, 650, TBX, TRV, H1, V-Twin 4x4 manual Preview image 3

2006 Arctic Cat 400, 500, 650, TBX, TRV, H1, V-Twin 4x4 manual Preview image 4

2006 Arctic Cat 400, 500, 650, TBX, TRV, H1, V-Twin 4x4 manual

Models covered in this manual:

2006 400 TBX ATV 4x4
2006 400 TRV ATV 4x4
2006 400 ATV 4x4
2006 500 TBX ATV 4x4
2006 500 TRV ATV 4x4
2006 500 ATV 4x4
2006 650 H1 ATV 4x4
2006 650 V-Twin ATV 4x4
- Production/model years: 2006

This repair manual covers the following serial numbers:

2006 Arctic Cat 400 4x4: all serial numbers
2006 Arctic Cat 500 4x4: all serial numbers
2006 Arctic Cat 650 H1 4x4: all serial numbers
2006 Arctic Cat 650 H1 4x4 TBX (dump bed): all serial numbers
2006 Arctic Cat 650 H1 4x4 TRV (2-up): all serial numbers
2006 Arctic Cat 650 V-Twin 4x4: all serial numbers
