Kubota 05 Series D905, D1005, D1105, V1205, V1305, V1505 Diesel Engine Workshop Manual 1994–present (P/N 97897-01643)
278 Pages • 1 Printable PDF (EN, FR, DE) • Download
Kubota Models Covered & Key Technical Specifications
Models: D905-B(E), D1005-B(E), V1205-B(E), V1205-T-B(E), V1305-B(E), D1105-B(E), V1505-B(E), D1105-T-B(E), V1505-T-B(E)
Sub-models / Variants: 3-cylinder, 4-cylinder, Vertical, water-cooled, 4-cycle diesel engine
Trade Names: 05 Series, Kubota 05 Series
Model Years: 1994–present
Serial Numbers: Engine Serial Number 489290 or lower, 489291 or higher; additional crankshaft screw specification break: 604086 or lower, 604087 or higher
-
Engine type: Vertical, water-cooled, 4-cycle diesel engine
-
Number of cylinders: 3 or 4
-
Combustion chamber type: N-TVCS (Engine Serial Number 489290 or lower); E-TVCS (Three Vortex Combustion System, Engine Serial Number 489291 or higher)
-
Fuel injection pump: Bosch MD type mini pump
-
Injection pressure: 13.73 MPa (140 kgf/cm2, 1991 psi)
-
Compression ratio: 22:1 or 22.5:1
-
Maximum bare speed: 3200 or 3800 rpm, depending on rated-speed version
-
Injection timing (Without timer): 0.31 to 0.35 rad. (18 to 20°) before T.D.C. for 3000 rpm versions; 0.37 to 0.40 rad. (21 to 23°) before T.D.C. for 3600 rpm versions
-
Electrical system: 12 V starter, 150 W or 360 W dynamo
Kubota Manual Features & Selected Content Preview
This Kubota 05 Series workshop manual covers the listed 1994–present diesel engines, from D905-B(E) through V1505-T-B(E), including naturally aspirated and turbocharged versions. P/N 97897-01643 identifies the manual with a May 1996 foreword and December 1999 printing.
PDF Search, Section Bookmarks, and Languages
Text search and electrical detail: An embedded OCR layer supports searches through the main text, with recognition errors and omissions; the publisher’s imprint details are not searchable. Eight bookmarks provide broad section navigation. Small electrical labels require zooming.
Supplied as one printable PDF with English, French, and German text. The 278-page PDF includes 274 pages of manual content and front matter, one front cover, two blank pages, and one publisher’s imprint page.
Engine Overhaul, Injection Testing, and Component Diagnosis
The following selected topics outline the repair and diagnostic coverage rather than reproduce the full contents. Other examples include fuel-pipe inspection and air-cleaner maintenance.
-
Engine repair: Compression testing, cylinder-head and valve service, timing-gear inspection, piston and crankshaft removal, bearing-clearance checks, and cylinder reconditioning.
-
Fuel injection: Injection-timing adjustment, pump-element and delivery-valve leakage tests, nozzle-pressure and spray-pattern checks, nozzle rebuilding, and fuel-system bleeding.
-
Lubrication and cooling: Oil-pressure testing, oil-pump clearance checks, thermostat testing, radiator and cap leakage checks, and water-pump service.
-
Electrical diagnosis: Starter motor and solenoid tests, glow-plug resistance checks, alternator repair, and component wiring and test diagrams.
-
Turbocharger service: Air and exhaust leak checks, wheel-shaft inspection, axial and radial clearance checks, housing cleaning, and assembly removal and installation.
-
Service references: Displacement and horsepower data, tightening torques, factory clearances and wear limits, maintenance checklists, performance curves, dimensional drawings, and valve-timing tables.
Written for servicing personnel, this manual includes internal engine repair procedures that call for precision measuring equipment and dedicated diesel test tools.
Cylinder-Head and Bottom-End Repair
Mechanism sections explain the cylinder block, head, crankshaft, connecting rods, and camshaft assemblies. Cylinder-head coverage extends to crack detection, valve-seat correction, guide replacement, and spring testing.
The manual provides step-by-step procedures for piston and connecting-rod removal and reassembly. Crankshaft alignment, cylinder boring and honing, and oversize piston selection extend the coverage into internal engine repair. Specification tables distinguish factory dimensions from allowable wear limits.
Serial-specific parts: N-TVCS engines through serial 489290 differ from E-TVCS engines starting at 489291. Cylinder-head and nozzle heat-seal changes, glow-plug specifications, and revised injection-pump shims help match replacement parts and service data to the engine before repair.
A separate serial break at 604086/604087 changes the crankshaft screw torque specification. Piston-installation cautions explain how incorrect insertion can scratch chrome-plated surfaces and cause cylinder trouble.
Injection Pump, Governor, and Timing
The fuel section explains the Bosch MD type mini injection pump, delivery valves, injection nozzles, and fuel filter. Injection-control diagrams show how the pump regulates fuel delivery.
Timing and calibration: Coverage distinguishes engines with and without the optional automatic advance timer, including serial-specific shim arrangements. Governor-shaft and fork-lever service accompany explanations of the centrifugal mechanical governor and timer mechanism.
Kubota cautions against routine injection-pump disassembly. Pump-element replacement requires fuel-delivery adjustment on a specified calibration bench.
Tool references include nozzle tester 07909-31361 and dimensioned drawings for making an injection-pump pressure tester. Troubleshooting tables connect starting problems, irregular running, exhaust smoke, low output, and overheating with possible causes and relevant service sections.
Oil Pressure and Cooling Components
The lubrication-flow diagram traces the trochoid oil pump, relief valve, pressure switch, and oil passages. Oil-pressure testing uses tester 07916-32031, with diagnostic checks for low pressure.
Cooling-system explanations cover thermostat operation and radiator construction. Water-pump disassembly identifies the shaft, impeller, and mechanical seal, with replacement and reassembly notes.
Starter and Alternator Repair
Starter coverage extends to the solenoid’s pull-in and holding coils, brushes, commutator, and overrunning clutch. Alternator procedures address output specifications, stator and rotor checks, slip rings, rectifier diodes, and the IC regulator.
The IC Regulator circuit, Rectifier schematic, and Magnet Switch Test connection view support engine-component diagnosis. This is an engine manual; complete host-machine wiring is outside its scope.
Turbocharger Inspection and Service Limits
Exploded and sectional views explain the turbine, compressor, bearing, and oil-seal arrangements. Housing removal and cleaning are covered, but the manual specifically prohibits separating the compressor wheel from the turbine shaft.
Oil-pipe handling cautions explain how contamination can damage the turbocharger’s internal oil passages.
Working on diesel equipment involves high-pressure fuel systems and heavy components; follow the manual’s safety precautions and proper lifting practices.
A Preview of Valve-Clearance and Thermostat Specifications
For the listed engines, the cold valve-clearance specification is 0.145 to 0.185 mm (0.0057 to 0.0072 in.), accompanied by an adjustment chart for the different cylinder layouts.
Thermostat test data distinguish a valve-opening range of 69.5 to 72.5 °C (157.1 to 162.5 °F) from the fully open temperature of 85 °C (185 °F).
